DC SPD 600V Type 1+2 VAL-MS-T1/T2 600DC-PV/2+V Lightning/Surge Arrester 2801163
Brand: Phoenix Contact
Category: Surge Protection Devices
- Model: 2801163
- Lightning current arrester / surge protective device for 2-pos. isolated and grounded 600 V DC PV voltage systems, for DIN rail mounting,
- 3-pos. base element, three pluggable temperature-monitored protective elements, status message at each plug.
- Product type: PV arrester
- Product family: VALVETRAB MS
- IEC test classification: PV I / II
PV T1 / T2 - EN type: T1 / T2
- IEC power supply system: DC
- Type: DIN rail module, two-section, divisible
- Distance between live and grounded parts: 8 mm
- Installation location: Interior
- Installation location of the disconnect device: Internal
- Accessibility: Accessible
- Connection configuration: Y configuration
- SPD failure behavior: OCFM (Open-Circuit Failure Mode)
- Surge protection fault message: optical
