- Increased safety, thanks to compliance with standard EN 50539-11 Reliable contact, thanks to integrated rotating latch Easy replacement, thanks to plug-in arresters Optimum inverter protection, thanks to low protection level Efficient replacement of defective plugs, thanks to visual status indicator Protection against mismatching, thanks to keyed plugs and base elements
- IEC test classification PV II PV T2 EN type T2 IEC power supply system DC Type Male Product type Replacement plug Product family VALVETRAB MS Installation location Interior Installation location of the disconnect device Internal Accessibility Accessible SPD failure behavior OCFM (Open-Circuit Failure Mode) Surge protection fault message optical Insulation characteristics Overvoltage category III Pollution degree 2
- Voltage (U): Up (Operating Voltage): 1000V - This could be the nominal operating voltage of the circuit breaker. Ucpv (Maximum Continuous Operating Voltage): 585V DC - This could be the maximum continuous operating voltage that the circuit breaker is designed to handle.
- Current (I): In (Rated Current): 15 kA - This is the rated current at which the circuit breaker is designed to operate continuously. Imax (Maximum Breaking Capacity): 40 kA - This is the maximum fault current that the circuit breaker can safely interrupt without sustaining damage.
- Breaking Capacity: The breaking capacity (Imax) of 40 kA indicates the maximum current the circuit breaker can safely interrupt under short-circuit conditions.
- Voltage and Current Protection: Ucpv (Voltage Protection): 585V DC - This could be the voltage level at which the circuit breaker provides protection.
- Iscpv (Short-Circuit Protection): 2000 A - This could be the short-circuit current at which the circuit breaker operates to protect the circuit.
