Phoenix Multi-functional Timer Relay (50 ms - 10 h) TR-ES-MUL-24/240-10H

Service life electrical

approx. 1x 105 cycles

Nominal frequency

48 Hz ... 63 Hz

Nominal power consumption

8 VA (1 W, 230 V AC)

0.4 W (at 24 V DC)

Test voltage relay winding/relay contact

1.6 kV

Rated insulation voltage

300 V

Rated surge voltage

2500 V

Nominal power consumption

8 VA (1 W, 230 V AC)

0.4 W (at 24 V DC)

Input voltage range

24 V DC ... 48 V DC -10 % ... +10 %

24 V AC ... 240 V AC -15 % ... +10 %

Temperature coefficient, typical

< 0.05 %/°C

Recovery time

> 100 ms

Setting range time

50 ms ... 10 h (6 time end ranges)

Basic accuracy

< 1.5 % (of scale end value)

Setting accuracy

< 5 % (of scale end value)

Repeat accuracy

< 0.5 % ±5 ms

Connection name

Non-floating, terminals A1-B1

Control pulse length

≥ 25 ms (DC)

≥ 50 ms (with AC)

Contact type

1 floating changeover contact

Maximum switching voltage

250 V AC

Interrupting rating (ohmic load) max.

1250 VA (5 A / 250 V AC)

Output fuse

5 A (fast-blow)
