Solid NDT Digital Concrete Test Hammer Concrete Rebound hammer HT225-W+

Solid NDT Digital Concrete Test Hammer Concrete Rebound hammer HT225-W+

The Digital Concrete Rebound Hammer HT-225W+ is a cutting-edge and sophisticated non-destructive testing device widely used in the field of civil engineering and construction. This advanced tool, also known as a Schmidt hammer or rebound hammer, is designed to assess the compressive strength of concrete structures accurately and efficiently. It offers a range of features and capabilities that make it an invaluable asset for engineers, contractors, and quality control professionals.

Rs. 339,000.00 Rs. 190,000.00

Digital Test Hammer is a high-tech product especially designed for the needs of in place test for concrete compressive strength, applied to non-destructive test (NDT) hardened concrete compressive strength component in construct projects. Digital Test Hammer for the quick and easy determination of the strength of concrete and hardness of construction materials. Digital and voice functions allow faster and greater number of test, leading to better quality tests. It's a good and useful instrument for quality control and inspection organizations. Its power source is AA akaline or lithium, customer can equip it anywhere.

Features:

  • Voice service LCD and scale readings are double guarantee the accuracy of the test values. When in-site test in case without power still can get the measure results through the scale. Voice service can improve the efficiency of work at special environment.
  • Machine core applies imported metal material high precision long service life.
  • The host and sensor integration design easy to operate and efficient.
  • High-resolution LCD color screen 176*220
  • Power source is 4 pcs of AA alkaline batteries
  • USB fast communication with PC
  • Easy to operate friendly system interface
  • Non-contact metal reflection grating + reflective encoder sensing high accuracy
  • The difference between displayer and scale <=0.5

Model HT225-W+
Measuring ranges 10-60 MPa
Impact energy 2.207J
2.207±0.1J(0.225Kgf.m) 785N/m
The staticfriction of pointer slider 0.65N±0.15N
Radius of friction of pointer slider 75mm
The average rebound values on steel anvil 80±2
Data storage 480000 testing results 20 special test strength curves could also be planted into
Size L280mm*D54mm
N W 1.2kg

What’s in the box: Test hammer*1,USB cable*1,instrument case*1,CD Disc*1,Abrasive Stone*1
